Alien Hydroponics V-System DWC

Alien Hydroponics V-System DWC - 21 Pot 3 Row

Transform your indoor gardening experience for the better with the Alien Hydroponics V-System Deep Water Culture Kit.

The V-System deep water culture hydroponic system is made to improve how you grow plants in confined spaces with cutting-edge features for optimal plant health and maximum yields.

This hydroponic kit uses the Venturi Valve Technology to ensure proper oxygenation in the root zones of your plants. There is no need to deal with clogged airstones or complicated air pumps, as the V-System Kit creates a powerful whirlpool vortex to distribute the nutrients to your plants equally.

The V-System hydroponic bucket system also features a modular design. You can customize the bucket layout as your garden evolves.

As a safety feature, the V-System hydroponic kit has a temperature control to ensure cooler water temperatures and reduce the risk of root rot.

Alien Hydroponics V-System 21 Pot Features

Venturi Valve Technology

The V-System deep water culture kit uses Venturi Valve Technology to ensure healthier root zones by optimizing oxygenation.

Temperature Control

Reduce root rot chances with the built-in temperature control of the V-Sys hydroponic kit.

Modular Design

When you’re ready to expand your system, you can customize the layout up to four rows with ten pots in each row for optimal distribution in each pot.

Equal Nutrient Distribution

The V-System hydroponic kit ensures equal nutrient distribution so all plants grow healthy.

Alien Hydroponics V-System 21 Pot Highlights

15 gallon (58L) V-POT
20 V-Pots
Three rows
1500-watt Jet-Stream Vortex pump -3 Row
Total-drainage bases
Venturi injectors
Five-inch spiral tubing
Five-inch Dual-Flow fittings
Integrated filtration
T304 Stainless clamps
Push-fit feed connections
Expandable up to four rows, ten pots per row

What is Included in the Alien Hydroponics V-System 21 Pot?

1x V-SYSTEM Vortex Water Pump 1500W 240V 22500 l/h
21x V-Pot 58L
21x V-Pot Base
21x V-Pot Lid
21x V-Pot Lid Inspection Cover
21x Square Net Pot
21x V-Pot Clip
21x Air Filter for V-SYSTEM Venturi, 6mm
21x Silencer for Venturi
21x Venturi Fitting
21x Venturi Air Inlet Pipe 6mm Blue (2X 4")
22x Nut 5"
22x Washer 5" Green Silicone
50x 5" Stainless Steel Clamp
1x Distribution Tee 50mm
3x DM Push-Fit Elbow 28mm V-SYSTEM
21x DM Push-Fit Tee 28-15mm V-SYSTEM
1x 1/2" Drain Cap Fitting
1x Drain Tap 1/2"-16mm Barb
2x Elbow 5" Barbed with Drain Point
4x Elbow 5" Threaded Dual-Flow
1x Filter Manifold Complete 50mm-2"
1x Float Valve
1x V-SYSTEM Header Pot 20L 50mm
1x Silver Lid
1x Header Pot Blank
1x Hosetail 16mm-3/4" Female Green
21x Venturi Inlet Fitting for 28mm Pipe
21x Pipe 28mm White Rigid 1 Meter - Venturi Feed
5x Pipe 50mm Silver 1 Meter
23x Pipe 5" Silver Spiral 80cm
2x Tee 5" Barbed
18x Tee Threaded 5" Dual-Flow
2x Threaded Tank Connector 1"
1x Vortex Pump Inlet Manifold 50mm
2x 1" Cap for Chiller Connections
1x 50mm Straight Dual Flow Fitting
1x Elbow 50mm Barbed
1x Terminal Manifold Left 50mm
1x Terminal Manifold Center 50mm
1x Terminal Manifold Right 50mm
54x 28mm Insert for 28mm Rigid Pipe
3x 28mm Push-Fit Stop End
12x Clamp Size 4
1x 8mm Screwdriver for 5" Clamp
1x Wrench 5"
1x Wrench for Float Valve
1x 8mm Socket for 5" Clamp
1x Pipe Cutter 50mm
6x Silicone Grease - Food Grade

Alien Hydroponics V-System 21 Pot Specifications

Number of pots:	21
Number of rows:	3
Kit total fluid volume:	342.9 gallons (1298 L)
Minimum assembled size (can space pots more widely for a larger footprint):
Length:	14' 0.1" (168.1 inches / 4270 mm)
Width:	5' 9.3" (69.3 inches / 1760 mm)
Water Pump Included with the Kit:
Model:	V-SYSTEM Vortex Water Pump 1100W 120V 17700 l/h
Wattage:	1500 watts
Flow Rate:	5944 gal/hr (22500 L/hr)
Recommended water chiller minimum capacity:	528 gallons (2000 L)

Alien Hydroponics V-System 21 Pot Manual

Alien Hydroponics V-System 21 Pot Instruction Manual

Alien Hydroponics V-System 21 Pot Technical Drawing

Alien Hydroponics V-System 21 Warranty

Alien Hydroponics provides a 3-year warranty for all parts and a standard 1-year warranty for pumps.
