Autopilot Dual Outlet 7-Day Grounded Digital Programmable Timer

  • 1725W maximum load capacity shared across both outlets
  • 8 independent on/off cycles per day with 1-second precision
  • 7.5 inch x 5.3 inch compact frame with grounded dual outlets
  • View More Details

Earn 24 points for shopping and get $0.24 off your next order. Join Harvest Club for free.

Questions? Talk to a specialist. Mon–Fri, 9am–5pm PST
Free Shipping On Most Items* To the lower 48
Transparent Pricing Backed w/ price match guarantee
Secure Checkout SSL encrypted payments

Send Us a Message

Ask Sage about this product
VOLUME PRICING

Commercial & Bulk Purchasing

We support operations & licensed facilities with volume pricing, dedicated account managers, and custom equipment consultation.

Commercial Inquiry

Contact Information
THROUGH THE Cultivator's LENS Hands-On Evaluation

  • You are coordinating multiple pieces of gear because manual switching leads to timing gaps in your cycles.
  • You are upgrading to digital control because your mechanical timers shift or drift over several days of operation.

  • The 1-second interval is tighter than what you get with standard dial timers, which helps for specific ventilation runs.
  • We use these for light banks since the dual outlets handle the load without needing extra power strips.

  • Users who synchronized their lights and fans say they saved time by not adjusting two separate systems every week.
  • Growers who switched to this digital unit say they stopped worrying about drifting schedules after a power flicker.

Autopilot Dual Outlet 7-Day Grounded Digital Programmable Timer, 1725W, 15A, 1 Second On/Off

Need to control two different pieces of equipment with the same precise timing schedule but want the flexibility of advanced digital programming?

The Autopilot Dual Outlet 7-Day Digital Timer provides 1-second precision timing for two grounded outlets simultaneously, with up to 8 on/off cycles per day across a full weekly program.

Perfect for growers who need to synchronize multiple devices like lights and fans, or coordinate lighting with ventilation systems, while maintaining the advanced programming capabilities of digital timing control.

This digital timer offers 7-day weekly programming with different schedules possible for each day of the week. Both outlets operate simultaneously on the same timing schedule, with each day programmable for up to 8 separate on/off cycles and 1-second precision for applications requiring exact timing coordination.

The dual outlet design allows you to control complementary equipment that needs identical timing - such as multiple lights, coordinated fans and pumps, or synchronized hydroponic systems. The 15-amp capacity and 1,725-watt maximum output is shared across both outlets, safely handling most grow room equipment combinations.

Built for reliability with UL-listed safety certification (E218111) and grounded outlet protection for both outputs. The digital display provides clear monitoring of current time, programmed schedules, and operational status. The compact 7.5" x 5.3" x 4.3" design and 0.51-pound weight makes installation straightforward in any indoor growing environment.

Product Highlights

  • Dual outlet control with simultaneous 7-day programming
  • 8 on/off cycles per day for complex automation sequences
  • 1-second precision timing for exact equipment coordination
  • 15-amp/1,725-watt shared capacity across both outlets
  • Digital display shows programming status and current time

Autopilot Dual Outlet Digital Timer Features

🔌
Dual Outlet Control

Two grounded outlets operate simultaneously on same 7-day schedule

📅
7-Day Programming

Weekly schedules with different programs for each day of the week

🔄
8 Daily Cycles

Up to 8 separate on/off cycles per day for complex coordination

⏱️
1-Second Precision

Exact timing control for precise equipment synchronization

📱
Digital Display

LCD shows current time, programs, and operational status for both outlets

🛡️
UL-Listed Safety

Certified safety with dual grounded outlets and 15A overload protection

Autopilot Dual Outlet Digital Timer Specifications

Specification Value
Outlets 2 Grounded Outlets (Simultaneous)
Programming Cycle 7-Day Weekly
Daily Cycles Up to 8 On/Off per Day
Timing Precision 1 Second On/Off
Voltage 120V
Rated Amperage 15 Amps (Shared)
Rated Wattage 1,725 Watts (Shared)
Dimensions (Unit) 7.5"L x 5.3"W x 4.3"H
Weight 0.51 lbs
UL Registration E218111
Usage Indoor Use Only

Autopilot Dual Outlet Digital Timer Manual

Autopilot Dual Outlet Digital Timer FAQs

What equipment combinations work best with dual outlet simultaneous control? +

Ideal combinations include multiple grow lights that need identical schedules, coordinated lighting and ventilation systems, synchronized pumps and air stones for hydroponics, or complementary equipment like lights with circulation fans. Both outlets follow the same 7-day programming, making them perfect for equipment that must operate together.

How is the 15A/1,725W capacity shared between the two outlets? +

The 15-amp and 1,725-watt capacity is the total maximum across both outlets combined, not per outlet. For example, you could run an 800W light in one outlet and a 900W device in the other (totaling 1,700W), but not two 1,000W devices. Always ensure your total load across both outlets doesn't exceed the 15A/1,725W limit.

Can I program different schedules for each outlet independently? +

No, both outlets operate simultaneously on the same 7-day programming schedule. When the timer turns ON, both outlets receive power; when it turns OFF, both outlets lose power. If you need independent control of two devices, you would need two separate single-outlet timers or look for a timer specifically designed for independent dual-outlet control.

What advantages does this have over using two single-outlet timers? +

The dual outlet timer ensures perfect synchronization between devices since they're controlled by the same internal clock and programming. This eliminates timing drift that can occur between separate timers. It also saves wall outlet space, reduces programming effort (one setup instead of two), and provides guaranteed coordination for equipment that must operate together precisely.

How complex can I make the weekly programming with 8 daily cycles? +

Very complex schedules are possible. Each day of the week can have up to 8 separate on/off periods, each with 1-second precision. You could program different lighting schedules for different phases of growth, create progressive weekly schedules, or coordinate complex hydroponic cycles that change throughout the week - all while maintaining perfect synchronization between both outlets.

What safety features protect against overloading both outlets? +

The UL-listed design (E218111) includes overload protection that monitors the total amperage across both outlets. If the combined load exceeds 15 amps, the safety system will shut down both outlets to prevent overheating or electrical hazards. Both outlets are grounded for additional equipment protection, and the digital display may show error indicators if problems occur.

Is this timer better suited for lighting or hydroponic applications? +

The Autopilot dual outlet timer excels at both applications. For lighting, it's perfect for coordinating multiple lights or lights with ventilation. For hydroponics, it's ideal for synchronizing pumps with air stones, coordinating multiple system components, or running complementary equipment that must operate together. The 1-second precision and 8 daily cycles support both simple and advanced applications.
