Alien Hydroponics RDWC 18 Pot System

Alien Hydroponics RDWC - 18 Pot 2 Row

Tired of complex hydroponic setups that don't deliver professional results? The ALIEN RDWC 18 Pot 2 Row Kit is the solution, offering commercial-grade recirculating deep water culture (RDWC) performance in a system engineered for explosive growth and simplicity.

Designed for serious home growers and commercial cultivators, this 18-pot system from Alien Hydroponics provides an abundance of oxygen and nutrients directly to the root zone. This creates the ideal conditions for rapid development and helps prevent common issues like root clogging and oxygen deficiency that can limit your plant's potential. This modular design is also available in other configurations, like the 16 pot or 20 pot versions, to perfectly fit your space.

Choose between 5-gallon (20L) or 9.5-gallon (36L) pots and configure your header for flexible placement in any grow tent or room. The tool-free, no-glue assembly ensures a quick, hassle-free setup, making the transition to professional hydroponics straightforward for growers at any experience level.

What's Included

1x RDWC Circulation Water Pump 30
1x RDWC Header Pot Complete
18x RDWC Pot 20L
19x Silver Lid
1x Header Pot Blank
18x Square Net Pot
18x Air Injection Ring
4x Elbow 50mm Dual Flow
32x 50mm Straight Dual Flow
1x Tee 50mm Dual Flow
37x Washer 50 X 64mm
37x Nut 50mm Dual Flow
1x RDWC Tee, Ball Valve and Filter
1x Tee 16mm Barbed
2x Plug - 16mm
1x Elbow 16mm Barbed
18x Tee 16mm - 6mm Blue
18x Pot Clip 16mm
13x Pipe 6mm Blue Bulk by Meter
13x Pipe 16mm Silver Bulk by Meter
6x Pipe 19mm Blue Bulk by Meter
10x Pipe 50mm Silver 66cm Piece
1x Wrench 50mm
1x Pipe Cutter 50mm
1x RDWC Instructions

Features

🚀

Accelerated Growth

Delivers an oxygen-rich nutrient solution to reduce veg time and boost yields.

🌊

Dual-Flow™ Fittings

Oversized 2" fittings prevent root clogging for uninterrupted nutrient flow.

🧩

Modular & Scalable

Easily adapts to any grow space and allows for future expansion.

💰

Cost-Efficient

Requires minimal growing medium and recirculates water to reduce operational costs.

💨

Superior Oxygenation

JET-STREAM A.I.R.™ rings provide constant, high-pressure oxygen to the root zone.

🔧

Simple Assembly

Threaded fittings and snap-on pipes allow for a quick, glue-free setup.

🛡️

Heat-Reflective Design

Silver polymer construction reflects heat, keeping the nutrient solution cool.

⚙️

Customizable Layout

Choose your pot size and header placement to maximize your growing area.

Setup and Maintenance

System Setup Steps:

1. Prepare Pots

Attach the necessary fittings to the pots.

2. Connect the System

Use piping to connect the pots and the header pot to establish the recirculating network.

3. Install Air System

Set up the air pump and connect it to the air stones in the pots.

4. Integrate Pumps

Install the water pump(s) for recirculation and chilling (if applicable).

5. Set Up Nutrient Tank

Connect the nutrient tank to the system.

6. Fill the System

Add water to the system.

Maintenance Tips:

Maintain water temperature between 18-20°C (64-68°F).
Add nutrients to the system and allow for recirculation before testing and adjusting.
When planting, use a substrate layer in the net pot, water the cutting, and fill the remaining space with substrate.
Fill the system using a hose, ensuring the correct level before turning on the pump.
Drain the system as needed by connecting a pipe to the designated fitting.
Use preventative solutions to maintain root health and system cleanliness.

Specifications

Specification	Value
Number of pots	18
Number of rows	2
Kit total fluid volume	20L Pot: 80.3 gal / 304 L 36L Pot: 141.2 gal / 534.4 L
Min. Assembled Size (Length)	20L Pot: 141⅜" 36L Pot: 172⅞"
Min. Assembled Size (Width)	20L Pot: 31⅛" 36L Pot: 37⅜"
Max. Assembled Size (Compact Header - Length)	20L Pot: 216⅞" 36L Pot: 267⅜"
Max. Assembled Size (Compact Header - Width)	20L Pot: 37" 36L Pot: 46⅛"
Max. Assembled Size (Remote Header - Length)	20L Pot: 256¼" 36L Pot: 306¾"
Max. Assembled Size (Remote Header - Width)	20L Pot: 37" 36L Pot: 46⅛"
Water Pump Included	RDWC Circulation Water Pump 30: 500 GPH, 45 Watts
Air Pump Option (With)	Air Pump 20: 52.8 GPM / 200 LPM, 195 Watts
Air Pump Requirement (Without)	Requires pump capable of delivering 47.6 GPM / 180 LPM

Support & Manuals

📄User Manual

Warranty

The Alien Hydroponics RDWC system comes with a one-year warranty for your peace of mind.

FAQs

What is the main advantage of an RDWC system?+

A Recirculating Deep Water Culture (RDWC) system constantly circulates a super-oxygenated nutrient solution through the root zone. This leads to explosive root growth, faster vegetative cycles, and significantly larger yields compared to many other methods.

How does the Dual-Flow™ fitting help my plants?+

The patent-pending 2-inch Dual-Flow™ fittings are designed to be much larger than standard fittings. This significantly reduces the chance of roots clogging the pipes, ensuring your plants receive a consistent and reliable flow of nutrients and oxygen at all times.

Is this system difficult to set up?+

No, the Alien RDWC system is designed for easy, tool-free assembly. It uses threaded fittings and snap-on pipes, so no glue is required. This makes setup, reconfiguration, and maintenance much simpler than traditional systems.

What's the difference between the 20L and 36L pot options?+

The 36L (9.5-gallon) pots provide more room for root development compared to the 20L (5-gallon) pots. This makes them ideal for growing larger plants or for longer growth cycles where a more extensive root mass is expected.

Do I need to buy a separate air pump?+

You have the option to purchase the kit with a high-powered air pump included. If you choose the 'Without Air Pump' option, you will need to supply your own pump capable of delivering at least 47.6 gallons per minute (180 liters per minute) to ensure adequate oxygenation for all 18 pots.

How is this different from the Alien V-SYSTEM?+

The main difference is the oxygenation method. The RDWC system uses JET-STREAM A.I.R.™ rings and an air pump to inject oxygen into the water. The Alien V-SYSTEM uses a venturi pump to create a vortex that draws air into the water, eliminating the need for a separate air pump.
