Alien Hydroponics RDWC - 16 Pot 4 Row
- Supports high-density growth for 16 plants using 20L or 36L pot options
- 2-inch Dual-Flow fittings with root-blocking slots for high volume circulation
- Tool-free assembly with threaded fittings and silver heat-reflective polymer
- View More Details
Earn 1,839 points for shopping and get $18.39 off your next order. Join Harvest Club for free.
Commercial & Bulk Purchasing
We support operations & licensed facilities with volume pricing, dedicated account managers, and custom equipment consultation.
Who This Is For
- You are upgrading to a 16-pot system because your current hand-watered setup makes growth rates too unpredictable.
- You are scaling to a 4-row layout because managing separate reservoirs for each plant takes up too much of your time.
What We Found
- Those oversized two inch fittings are the real hero here because they handle massive root balls without clogging.
- The silver polymer pots keep the solution noticeably cooler than standard black buckets under high intensity lights.
What Users Say
- Growers who switched from drain to waste say they cut their nutrient costs by nearly half in the first full cycle.
- Users who moved to this 16 pot layout report they stopped worrying about root rot even during peak summer heat.
Alien Hydroponics RDWC - 16 Pot 4 Row
Struggling to achieve professional hydroponic results at a larger scale? The Alien Hydroponics RDWC 16 Pot 4 Row kit eliminates the guesswork, delivering a commercial-grade recirculating deep water culture (RDWC) system designed for maximum growth and minimal complexity. It's the perfect solution for experienced home growers or boutique commercial operations aiming for consistent, high-yield production.
This advanced RDWC hydroponic system provides a constant flow of super-oxygenated nutrient solution directly to the root zone, creating the ideal environment for explosive growth and preventing common issues like root rot and nutrient deficiencies. The entire Alien Hydroponics lineup is engineered for performance, and this 16-pot kit is a prime example of that commitment to quality and innovation.
Choose between 5-gallon (20L) or 9.5-gallon (36L) pots and configure the layout to perfectly fit your space. Thanks to a tool-free, no-glue design, setup is quick and maintenance is straightforward, allowing you to focus on what matters most: cultivating healthy, thriving plants.
What's Included
- 1x RDWC Circulation Water Pump 2
- 1x RDWC Header Pot Complete
- 16x RDWC Pot 20L
- 17x Silver Lid
- 1x Header Pot Blank
- 16x Square Net Pot
- 16x Air Injection Ring
- 6x Elbow 50mm Dual Flow
- 24x 50mm Straight Dual Flow
- 33x Washer 50 X 64mm
- 33x Nut 50mm Dual Flow
- 2x RDWC Tee, Ball Valve and Filter
- 3x Tee 16mm Barbed
- 4x Plug - 16mm
- 2x Elbow 16mm Barbed
- 16x Tee 16mm - 6mm Blue
- 16x Pot Clip 16mm
- 1x Tee 19mm Barbed
- 12x Pipe 6mm Blue Bulk by Meter
- 15x Pipe 16mm Silver Bulk by Meter
- 7x Pipe 19mm Blue Bulk by Meter
- 2x Pipe 50mm Silver 100cm Piece
- 11x Pipe 50mm Silver 66cm Piece
- 1x Wrench 50mm
- 1x Pipe Cutter 50mm
- 1x RDWC Instruction
Features
Accelerated Growth
Reduces vegetative time and boosts flowering for faster, more substantial harvests.
Dual-Flow™ Fittings
Oversized 2" fittings with unique slots prevent root blockage for consistent nutrient flow.
Modular & Scalable
Easily adapt the system to your space or expand it as your operation grows.
Cost-Efficient Operation
Requires minimal growing medium and recirculates nutrients, reducing operational costs.
JET-STREAM A.I.R.™
Delivers a constant, high-pressure flow of oxygen to promote explosive root development.
Tool-Free Assembly
Threaded fittings and snap-on pipes allow for a quick, glue-free setup and easy maintenance.
Durable Construction
Heat-reflective silver polymer helps maintain cooler solution temperatures for healthier roots.
Customizable Layouts
Offers multiple configurations to perfectly match your growing area and plant spacing needs.
Specifications
| Specification | Value |
|---|---|
| Number of pots | 16 |
| Number of rows | 4 |
| Kit total fluid volume (20L Pot) | 71.9 gallons / 272 liters |
| Kit total fluid volume (36L Pot) | 126 gallons / 476.8 liters |
| Min assembled size (Compact Header, 20L Pot) | 70½" L x 66½" W |
| Min assembled size (Compact Header, 36L Pot) | 84¼" L x 79⅛" W |
| Max assembled size (Compact Header, 20L Pot) | 98⅞" L x 123⅝" W |
| Max assembled size (Compact Header, 36L Pot) | 119⅝" L x 144½" W |
| Min assembled size (Remote Header, 20L Pot) | 74⅜" L x 66½" W |
| Min assembled size (Remote Header, 36L Pot) | 88¼" L x 79⅛" W |
| Max assembled size (Remote Header, 20L Pot) | 138¼" L x 123⅝" W |
| Max assembled size (Remote Header, 36L Pot) | 159" L x 144½" W |
| Water Pump (20L Kit) | RDWC Circulation Water Pump 20: 350 GPH, 35 Watts |
| Water Pump (36L Kit) | RDWC Circulation Water Pump 30: 500 GPH, 45 Watts |
| Optional Air Pump | Air Pump 20: 52.8 GPM / 200 LPM, 195 watts |
| Required Air Pump (if not included) | Minimum 42.3 GPM / 160 LPM |
Setup and Maintenance
System Setup Steps:
1. Prepare Pots
Attach the necessary fittings to the pots.
2. Connect the System
Use piping to connect the pots and the header pot to establish the recirculating network.
3. Install Air System
Set up the air pump and connect it to the air stones in the pots.
4. Integrate Pumps
Install the water pump(s) for recirculation and chilling (if applicable).
5. Set Up Nutrient Tank
Connect the nutrient tank to the system.
6. Fill the System
Add water to the system.
Maintenance Tips:
- Maintain water temperature between 18-20°C (64-68°F).
- Add nutrients to the system and allow for recirculation before testing and adjusting.
- When planting, use a substrate layer in the net pot, water the cutting, and fill the remaining space with substrate.
- Fill the system using a hose, ensuring the correct level before turning on the pump.
- Drain the system as needed by connecting a pipe to the designated fitting.
- Use preventative solutions to maintain root health and system cleanliness.
Support & Manuals
Warranty
Alien Hydroponics RDWC comes with a one-year warranty for your peace of mind.
Compare Alien Hydroponics Systems
| Feature |
|
|
Other RDWC Systems |
| Oxygenation method | Venturi | JET-STREAM A.I.R.™ rings | air stones (prone to clogging) |
| Set up without gluing | ✔ | ✔ | ✘ |
| Pot shape | round | square | rectangular |
| Customizable pot / plant spacing | ✔ | ✔ | ✘ |
| Header can be placed up to 39" / 100cm away (such as outside a tent) | ✔ | ✔ | ✘ |
| Does not require an air pump | ✔ | Adjustable flame dial, no smoke, easy to set up | Great heat output and lightweight design, easy to transport and carry |
| Patent-pending Dual-Flow™ fittings | ✔ | ✔ | A thoughtful design that combines great heat and easy to clean features |
| Silver reflective polymer pots and pipe to reject radiant heat, keeping nutrient solution cooler | ✔ | ✔ | ✘ |
| Easily-cleanable nutrient solution filters | ✔ | ✔ | ✘ |
| Float valve for automatic top-off | ✔ | ✔ | ✘ |
| Vortex maximizing nutrient and O2 distribution | ✔ | ✘ | ✘ |
| Fresh nutrient distribution direct to every pot | ✔ | ✘ | ✘ |
| Complete drainage possible | ✔ | almost | ✘ |
| External pump to minimize heat | ✔ | ✘ | ✘ |
| Plants can be rotated in their pots | 1°-360° | 90°, 180°, 270° (must lift the lid & plant) | 180° only (must lift the lid & plant) |
| Pot sizes available | 15.3 gallon (58L) | 5 gallon (20L) 9.5 gallon (36L) | 13 gallon or smaller |
| Recirculation line diameter (larger minimizes root clogging) | 5" | 2" | 2-3" or much smaller |
| Kit configurations available to best fit your space | 54 | 183 | 1 - 16 |
FAQs
Recirculating Deep Water Culture (RDWC) systems provide a constant flow of highly oxygenated, nutrient-rich water directly to the plant's roots. This leads to faster growth rates, healthier root systems, and significantly larger yields compared to many other hydroponic methods.
No, the system is designed for easy, tool-free assembly. It uses threaded fittings and snap-on pipes, so no glue is required. This makes setup, breakdown, and reconfiguration quick and simple.
The Alien Hydroponics systems incorporate unique, patented features like JET-STREAM A.I.R.™ rings for superior oxygenation and oversized Dual-Flow™ fittings that are specifically designed to prevent root clogging, ensuring your system runs smoothly and efficiently.
The system is constructed from a heat-reflective silver polymer that helps keep the nutrient solution cooler. For optimal results, maintain a water temperature between 64-68°F (18-20°C). In warmer environments, a water chiller may be beneficial.
Yes, the modular design allows for customization and expansion. You can reconfigure the layout or add more pots as your needs change. If you need a larger setup from the start, consider the Alien Hydroponics RDWC 20 Pot system or other available sizes.
The 36L (9.5-gallon) pots hold more water and provide more space for root development than the 20L (5-gallon) pots. This can be beneficial for growing larger plants or for growers who want a more stable system with less frequent pH and EC fluctuations.
