Alien Hydroponics V-System 4 Pot | DWC System with Vortex

Alien Hydroponics V-System DWC - 4 Pot 2 Row

Tired of complicated and underperforming deep water culture setups? The Alien Hydroponics V-System DWC Kit is engineered to transform your indoor garden, delivering explosive growth with unparalleled efficiency and ease of use.

At the heart of this innovative DWC hydroponic system is the revolutionary Venturi Valve Technology. This eliminates the need for noisy air pumps and unreliable airstones, instead creating a powerful whirlpool vortex in each pot. This vortex super-oxygenates the nutrient solution and distributes it evenly, ensuring every plant receives precisely what it needs for vigorous development.

The V-System is built for growth. Its modular design allows you to customize the layout to fit your space perfectly. As your garden expands, so can your system. This 4-pot configuration is a great starting point, but the V-System can be expanded to larger setups like the 6-pot V-System or even larger configurations. The entire Alien Hydroponics lineup is designed with scalability in mind.

What's Included

1x V-SYSTEM Vortex Water Pump 180W 120V 10800 l/h
4x V-Pot 58L
4x V-Pot Base
4x V-Pot Lid
4x V-Pot Lid Inspection Cover
4x Square Net Pot
4x V-Pot Clip
4x Air Filter for V-SYSTEM Venturi, 6mm
4x Silencer for Venturi
4x Venturi Fitting
4x Venturi Air Inlet Pipe 6mm Blue (2X 4")
4x Venturi Inlet Fitting for 22mm Pipe
5x Nut 5"
5x Washer 5" Green Silicone
15x 5" Stainless Steel Clamp
1x Distribution Tee 40mm
2x DM Push-Fit Elbow 22-15mm V-SYSTEM
2x DM Push-Fit Elbow 22mm V-SYSTEM
2x DM Push-Fit Tee 22-15mm V-SYSTEM
1x Drain Cap 1/2"
1x Drain Tap 1/2"-16mm Barb
2x Elbow 5" Barbed with Drain Point
3x Elbow 5" Threaded Dual-Flow
1x Filter Manifold, Complete 40mm
1x Float Valve
1x V-SYSTEM Header Pot 20L 40mm
1x Silver Lid
1x Header Pot Blank
1x Hosetail 16mm-3/4" Female Green
4x Pipe 22mm Rigid 1 Meter - Venturi Feed
1x Pipe 32mm Red 1 Meter Spiral
3x Pipe 40mm Silver 1 Meter Spiral
5x Pipe 5" Spiral 80cm
1x Tee 5" Barbed
2x Tee Threaded 5" Dual-Flow
2x Threaded Tank Connector 1"
1x Vortex Pump Inlet Manifold40mm long
2x 1" Cap for Chiller Connections
1x T/Connector Straight 32mm
1x T/Connector Straight 40mm
1x Terminal Manifold Left
1x Terminal Manifold Right
12x 22mm Insert for 22mm Barrier Pipe
2x Clamp Size 2
8x Clamp Size 3
1x 8mm Screwdriver for 5" Clamp
1x Wrench 5"
1x Wrench for Float Valve
1x 8mm Socket for 5" Clamp
1x Pipe Cutter 50mm
1x Silicone Grease - Food Grade

Features

🌀

Venturi Valve Technology

Eliminates air pumps and airstones, creating a super-oxygenated vortex for healthier roots.

❄️

Temperature Stability

Large-diameter fittings maintain cooler, more stable water temperatures to prevent root rot.

🧩

Modular & Expandable

Easily customize your layout and expand your system up to 40 pots as your garden grows.

🌿

Uniform Nutrient Delivery

Ensures every plant receives an equal and consistent supply of nutrients for uniform growth.

Alien Hydroponics V-System 4 Pot Specifications

Specification	Value
Number of pots	4
Number of rows	2
Kit total fluid volume	63.4 gallons (240 L)
Minimum Assembled Length	4' 7.1" (55.1 inches / 1400 mm)
Minimum Assembled Width	3' 11.2" (47.2 inches / 1200 mm)
Pump Model	V-SYSTEM Vortex Water Pump 180W
Pump Wattage	180 watts
Pump Flow Rate	2853 gal/hr (10800 L/hr)
Recommended Chiller Capacity	132 gallons (500 L)

Support & Manuals

📄Instruction Manual 📄Technical Drawing

Warranty

Alien Hydroponics provides a 3-year warranty for all parts and a standard 1-year warranty for pumps.

FAQs

What makes the V-System different from other DWC systems?+

The key difference is its innovative Venturi Valve Technology. Unlike traditional DWC setups that rely on air pumps and airstones, the V-System uses the flow of water to create a vortex that draws in oxygen. This results in higher dissolved oxygen levels, quieter operation, and eliminates the common issue of clogged airstones.

Is this system difficult to set up?+

The V-System is designed for straightforward assembly. The kit includes all necessary parts, push-fit connections, and detailed instructions to guide you through the process. You can find the instruction manual and technical drawings in the Support & Manuals section on this page.

Can I expand this 4-pot system later?+

Absolutely. The modular design is a core feature of the V-System. You can easily add more pots and rows to expand your garden as your needs grow. This 4-pot kit is a perfect starting point, and you can scale up to a larger configuration like the 8-pot V-System when you're ready.

How does the system keep the water cool?+

The V-System promotes stable water temperatures through its efficient design and large 5-inch tubing, which helps prevent heat buildup. While it does not include a chiller, it features dedicated connection points for easily integrating an external water chiller, which is recommended for optimal root health, especially in warmer environments.

What pump is included with this kit?+

This 4-pot kit comes with the powerful and reliable Alien Hydroponics V-SYSTEM Vortex 180W pump. It's specifically designed to drive the Venturi system effectively, ensuring consistent nutrient and oxygen circulation throughout all the pots.
