Alien Hydroponics V-System 21 Pot DWC System

Alien Hydroponics V-System DWC - 21 Pot 3 Row

Struggling to achieve consistent, large-scale results with your indoor garden? The Alien Hydroponics V-System DWC is engineered to eliminate the guesswork and supercharge your grow. This professional-grade 21-pot system provides an automated, highly oxygenated environment, creating the perfect conditions for explosive root development and massive yields with minimal intervention.

The revolutionary design uses Venturi Valve Technology to draw oxygen directly into the nutrient solution, creating a powerful vortex that eliminates the need for noisy air pumps and unreliable air stones. This ensures your plants receive a perfectly balanced mix of water, nutrients, and oxygen 24/7. Built for serious growers, this robust kit is part of a larger family of V-System DWC kits, with options ranging from a compact 4-pot setup to a massive 28-pot system to suit any space.

Features

💨

Venturi Valve Technology

Eliminates air pumps and stones by creating a super-oxygenated nutrient vortex for explosive root growth.

❄️

Optimal Temperature Control

Maintains cooler water temperatures to significantly reduce the risk of root rot and other diseases.

🧩

Fully Modular Design

Easily expand or customize your layout. This system is designed to grow with your cultivation needs.

🌊

Powerful Nutrient Circulation

The high-power Jet-Stream Vortex pump ensures every plant receives an equal and constant supply of nutrients.

What's Included

1x V-SYSTEM Vortex Water Pump 1500W 240V 22500 l/h
21x V-Pot 58L
21x V-Pot Base
21x V-Pot Lid
21x V-Pot Lid Inspection Cover
21x Square Net Pot
21x V-Pot Clip
21x Air Filter for V-SYSTEM Venturi, 6mm
21x Silencer for Venturi
21x Venturi Fitting
21x Venturi Air Inlet Pipe 6mm Blue (2X 4")
22x Nut 5"
22x Washer 5" Green Silicone
50x 5" Stainless Steel Clamp
1x Distribution Tee 50mm
3x DM Push-Fit Elbow 28mm V-SYSTEM
21x DM Push-Fit Tee 28-15mm V-SYSTEM
1x 1/2" Drain Cap Fitting
1x Drain Tap 1/2"-16mm Barb
2x Elbow 5" Barbed with Drain Point
4x Elbow 5" Threaded Dual-Flow
1x Filter Manifold Complete 50mm-2"
1x Float Valve
1x V-SYSTEM Header Pot 20L 50mm
1x Silver Lid
1x Header Pot Blank
1x Hosetail 16mm-3/4" Female Green
21x Venturi Inlet Fitting for 28mm Pipe
21x Pipe 28mm White Rigid 1 Meter - Venturi Feed
5x Pipe 50mm Silver 1 Meter
23x Pipe 5" Silver Spiral 80cm
2x Tee 5" Barbed
18x Tee Threaded 5" Dual-Flow
2x Threaded Tank Connector 1"
1x Vortex Pump Inlet Manifold 50mm
2x 1" Cap for Chiller Connections
1x 50mm Straight Dual Flow Fitting
1x Elbow 50mm Barbed
1x Terminal Manifold Left 50mm
1x Terminal Manifold Center 50mm
1x Terminal Manifold Right 50mm
54x 28mm Insert for 28mm Rigid Pipe
3x 28mm Push-Fit Stop End
12x Clamp Size 4
1x 8mm Screwdriver for 5" Clamp
1x Wrench 5"
1x Wrench for Float Valve
1x 8mm Socket for 5" Clamp
1x Pipe Cutter 50mm
6x Silicone Grease - Food Grade

Specifications

Specification	Value
Number of pots	21
Number of rows	3
Kit total fluid volume	342.9 gallons (1298 L)
Minimum assembled length	14' 0.1" (4270 mm)
Minimum assembled width	5' 9.3" (1760 mm)
Water Pump Model	V-SYSTEM Vortex Water Pump 1500W
Pump Wattage	1500 watts
Pump Flow Rate	5944 gal/hr (22500 L/hr)
Recommended water chiller capacity	528 gallons (2000 L)

Support & Manuals

📄Instruction Manual 📄Technical Drawing

Warranty

Alien Hydroponics provides a 3-year warranty for all parts and a standard 1-year warranty for pumps.

FAQs

Do I need an air pump or air stones with this system?+

No. The V-System's key innovation is its Venturi Valve Technology, which naturally draws air into the water stream to create a highly oxygenated vortex. This advanced method completely replaces the need for separate air pumps and porous air stones, resulting in a quieter, more efficient, and lower-maintenance setup.

What makes the V-System different from an Alien RDWC system?+

The main difference is the method of oxygenation and circulation. The V-System uses a powerful in-line pump and Venturi injectors to actively create an oxygen-rich vortex in each pot. In contrast, traditional Alien RDWC systems typically use a drop-in air pump and air stones in each pot. Both are excellent DWC hydroponics methods, but the V-System is designed for maximum oxygenation without external air pumps.

Is this system difficult to set up and maintain?+

The system is designed for straightforward assembly. We provide a detailed instruction manual and technical drawings to guide you. Maintenance is simpler than many other systems due to the absence of air stones that can clog. Regular tasks include monitoring pH and nutrient levels and periodic system cleaning between growth cycles.

Can I expand this system in the future?+

Absolutely. The V-System is fully modular. You can add more pots or rows to the system as your operation grows, making it a scalable investment for both hobbyist and commercial growers. The powerful included Vortex water pump is designed to handle expansion.

What size water chiller do I need for this system?+

For a system of this volume (343 gallons), a water chiller with a minimum capacity of 528 gallons (2000 L) is recommended to maintain optimal root zone temperatures and prevent issues like root rot.
