Alien Hydroponics RDWC 33 Pot System

Alien Hydroponics RDWC - 33 Pot 3 Row

Struggling to achieve consistent, large-scale results with your current hydroponic setup? The Alien Hydroponics RDWC 33 Pot 3 Row system is engineered to eliminate the complexities of commercial-grade growing, delivering explosive growth and massive yields. This professional recirculating deep water culture (RDWC) system provides an ideal, super-oxygenated environment directly to the root zone, fostering rapid development without the common pitfalls of root clogging or oxygen deficiency.

Designed for serious growers, licensed producers, and research facilities, this 33-pot system from Alien Hydroponics offers unparalleled control and stability. The modular design ensures it can be adapted to fit your specific space, with options for 20L or 36L pots and flexible header placement. Whether you're scaling up an existing operation or building a new one, this kit provides the foundation for success. For growers looking for a slightly different configuration, the 30 Pot 3 Row RDWC system offers a similar high-performance setup.

What's Included

1x RDWC Circulation Water Pump 40
1x RDWC Header Pot Complete
33x RDWC Pot 20L
34x Silver Lid
1x Header Pot Blank
33x Square Net Pot
33x Air Injection Ring
4x Elbow 50mm Dual Flow
60x 50mm Straight Dual Flow
3x Tee 50mm Dual Flow
67x Washer 50 X 64mm
67x Nut 50mm Dual Flow
2x RDWC Tee, Ball Valve and Filter
2x Tee 16mm Barbed
3x Plug - 16mm
2x Elbow 16mm Barbed
33x Tee 16mm - 6mm Blue
33x Pot Clip 16m
1x Elbow 20mm Barbed - 3/4" Male
1x Tee 19mm Barbed
24x Pipe 6mm Blue Bulk by Meter
24x Pipe 16mm Silver Bulk by Meter
8x Pipe 19mm Blue Bulk by Meter
2x Pipe 50mm Silver 100cm Piece
19x Pipe 50mm Silver 66cm Piece
1x Wrench 50mm
1x Pipe Cutter 50mm
1x RDWC Instructions

Features

🚀

Accelerated Growth

Reduces vegetative time and boosts flowering for faster, more substantial harvests.

🌊

Dual-Flow™ Fittings

Oversized 2" fittings minimize root blockage for consistent nutrient delivery.

🧩

Modular & Scalable

Easily adapt the system to various grow sizes and expand as your needs evolve.

💰

Efficient Operation

Requires minimal growing medium and recirculates solution to reduce operational costs.

💨

Superior Oxygenation

JET-STREAM A.I.R.™ rings provide constant, high-pressure oxygen to the root zone.

🔧

Tool-Free Assembly

Threaded fittings and snap-on pipes allow for a glue-free, straightforward setup.

🛡️

Durable Construction

Heat-reflective silver polymer maintains cooler solution temperatures for healthy roots.

↔️

Custom Configurations

Choose from multiple pot sizes and header options to perfectly fit your growing space.

Specifications

Specification	Value
Pot Options	33 x 20L (5 gal) Pots 33 x 36L (9.5 gal) Pots
Number of Rows	3
Total Fluid Volume	20L Pots: 143.7 gal / 544 L 36L Pots: 255.3 gal / 966.4 L
Min. Assembled Size (Compact Header)	20L Pots: 169⅝" x 48⅞" 36L Pots: 208¼" x 58¼"
Max. Assembled Size (Compact Header)	20L Pots: 264⅛" x 100" 36L Pots: 326⅜" x 115"
Min. Assembled Size (Remote Header)	20L Pots: 173⅝" x 66½" 36L Pots: 212¼" x 79⅛"
Max. Assembled Size (Remote Header)	20L Pots: 303½" x 100" 36L Pots: 365¾" x 115"
Included Water Pump	RDWC Circulation Water Pump 40: 700 GPH, 70 Watts
Optional Air Pump	Air Pump 40: 105.7 GPM / 400 LPM, 220 watts
Required Air Pump (if not included)	Minimum 87.2 GPM / 330 LPM

Setup and Maintenance

System Setup Steps:

1. Prepare Pots

Attach the necessary fittings to the pots.

2. Connect the System

Use piping to connect the pots and the header pot to establish the recirculating network.

3. Install Air System

Set up the air pump and connect it to the air stones in the pots.

4. Integrate Pumps

Install the water pump(s) for recirculation and chilling (if applicable).

5. Set Up Nutrient Tank

Connect the nutrient tank to the system.

6. Fill the System

Add water to the system.

Maintenance Tips:

Maintain water temperature between 18-20°C (64-68°F).
Add nutrients to the system and allow for recirculation before testing and adjusting.
When planting, use a substrate layer in the net pot, water the cutting, and fill the remaining space with substrate.
Fill the system using a hose, ensuring the correct level before turning on the pump.
Drain the system as needed by connecting a pipe to the designated fitting.
Use preventative solutions to maintain root health and system cleanliness.

Support & Manuals

📄User Manual

Warranty

The Alien Hydroponics RDWC system comes with a one-year warranty for your peace of mind.

FAQs

What is the main advantage of an RDWC system?+

Recirculating Deep Water Culture (RDWC) systems constantly circulate a super-oxygenated nutrient solution throughout the root zone. This process dramatically increases nutrient uptake and promotes explosive root development, leading to significantly faster vegetative growth and larger overall yields compared to other methods.

Can I expand this system in the future?+

Yes, all Alien Hydroponics RDWC systems are fully modular. The tool-free, no-glue design with threaded fittings makes it easy to add more pots or reconfigure the layout to adapt to your evolving growing needs and space requirements.

What makes this different from the Alien V-System?+

The primary difference is the oxygenation method. This RDWC system uses JET-STREAM A.I.R.™ rings to inject air directly into each pot. The Alien V-System, on the other hand, uses a venturi effect to draw air into the solution as it circulates, creating a vortex. Both are highly effective, but the RDWC is often preferred for its direct-to-root oxygen delivery.

How do the Dual-Flow™ fittings prevent root clogging?+

The patent-pending Dual-Flow™ fittings are oversized at 2 inches in diameter, which is significantly larger than many standard systems. This larger bore, combined with specially designed slots, allows root mass to pass through more freely, drastically reducing the risk of clogs and ensuring the nutrient solution flows consistently.

Do I need to buy a separate air pump for this kit?+

This kit is available with or without an air pump. If you choose the option without one, you must supply your own pump capable of delivering at least 87.2 gallons per minute (330 liters per minute) to properly oxygenate all 33 pots.
